KNOTS and BURLS TO BOWLS

Kilian Tools and Nanograin Carbide Cutters

Canadian woodturners Don Thur and Russ Lacombe collaborated to create a group of Kilian Tools and Nanograin Carbide Cutters to allow a wider range of the woodturning community to access a superior quality tool at a very reasonable cost. There will be no retail network in which to purchase our tools; they will only be available by purchase through this website or direct contact. All will be sold unhandled but we do recommend two handle makers, both woodturners as we: Doug Thompson @ www.thompsonlathetools.com or Lionel Bédard @ www.belgreenwood.com

Kilian Tools and Nanograin Carbide Cutters

Kilian Tool Set with 1/2" Shaft Kilian Tool Set with 3/8" Shaft Replacement Cutters Miscellaneous Ersatz Items

Kilian Tool Set with 1/2" Shaft

The 1/2" (12.7mm) shafts are Grade 304 Stainless Steel with the corners machined to fit in a handle drilled to 5/8" x 3" (15.9mm x 76.2mm)--the size of the tang, and CNC-machined to fit the individual Nanograin Carbide Cutter.
KL 0 Tool SetKL 0 Tool Set
click to enlarge
  • 1/2" (12.7mm) shaft
  • 15mm (.59") square Nanograin Carbide Cutter with a 30 degree bevel.
  • overall length: 11" (comprised of 8" shaft + 3" tang)
  • overall weight: 3/4 lb
  • screw
  • Allen wrench

CDN $53.85

  • KTS-KL-0
KL 150 Tool SetKL 150 Tool Set
click to enlarge
  • 1/2" (12.7mm) shaft
  • 15mm (.59") 4-sided Nanograin Carbide Cutter (slightly rounded) with a 30 degree bevel
  • overall length: 11" (comprised of 8" shaft + 3" tang)
  • overall weight: 3/4 lb
  • screw
  • Allen wrench

CDN $53.85

  • KTS-KL-150
KL 50 Tool SetKL 50 Tool Set
click to enlarge
  • 1/2" (12.7mm) shaft
  • 15mm (.59") 4-sided Nanograin Carbide Cutter (more radiused)with a 30 degree bevel
  • overall length: 11" (comprised of 8" shaft + 3" tang)
  • overall weight: 3/4 lb
  • screw
  • Allen wrench

CDN $53.85

  • KTS-KL-50
KL R Tool SetKL R Tool Set
click to enlarge
  • 1/2" (12.7mm) shaft
  • 16mm (.63") round Nanograin Carbide Cutter with 30 degree bevel
  • overall length: 11" (comprised of 8" shaft + 3" tang)
  • overall weight: 3/4 lb
  • screw
  • Allen wrench

CDN $53.85

  • KTS-KL-R

Kilian Tool Set with 3/8" Shaft

The 3/8" (9.5mm) shafts are Grade 304 Stainless Steel with the corners machined to fit in a handle drilled to 1/2" x 3" (12.7m x 76.2mm)--the size of the tang, and CNC-machined to fit the individual Nanograin Carbide Cutter.
KD 0 Tool SetKD 0 Tool Set
click to enlarge
  • 3/8" (9.5mm) shaft
  • 10.5mm (.41") square Nanograin Carbide Cutter with a 35 degree bevel
  • overall length: 11" (comprised of 8" shaft + 3" tang)
  • overall weight: 1/2 lb
  • screw
  • Allen wrench

CDN $47.70

  • KTS-KD-0
KD R Tool SetKD R Tool Set
click to enlarge
  • 3/8" (9.5mm) shaft
  • 11mm (.43") round Nanograin Carbide Cutter with a 30 degree bevel
  • overall length: 11" (comprised of 8" shaft + 3" tang)
  • overall weight: 1/2 lb
  • screw
  • Allen wrench

CDN $47.70

  • KTS-KD-R

Replacement Cutters

This Nanograin Carbide Cutter is exceptionally sharp and retains its edge for a remarkably long turning life. We recommend cutting at centre, otherwise these tools may become too aggressive.
KL 0 CutterKL 0 Cutter
click to enlarge
  • 15mm (.59") square Nanograin Carbide Cutter with a 30 degree bevel.

CDN $10.00

  • KTC-KL-0
KL 150 CutterKL 150 Cutter
click to enlarge
  • 15mm (.59") 4-sided Nanograin Carbide Cutter (slightly rounded)with a 30 degree bevel.

CDN $10.00

  • KTC-KL-150
KL 50 CutterKL 50 Cutter
click to enlarge
  • 15mm (.59") 4-sided Nanograin Carbide Cutter (more radiused)with a 30 degree bevel.

CDN $10.00

  • KTC-KL-50
KL R CutterKL R Cutter
click to enlarge
  • 16mm (.63") round Nanograin Carbide Cutter with a 30 degree bevel.

CDN $10.00

  • KTC-KL-R
KD 0 CutterKD 0 Cutter
click to enlarge
  • 10.5mm (.41") square Nanograin Carbide Cutter with a 35 degree bevel

CDN $9.00

  • KTC-KD-0
KD R CutterKD R Cutter
click to enlarge
  • 11mm (.43") round Nanograin Carbide Cutter with a 30 degree bevel.

CDN $9.00

  • KTC-KD-R

Miscellaneous Ersatz Items

additional screws for all cutters
  • For KL tools = 10/32 x 3/8 flathead.
  • For KD tools = 4/40 x 5/16 flathead.

CDN $0.25

  • CUTTSCREW
additional allen wrench
  • For KL tools = 1/8 short shaft.
  • For KD tools = 1/16 short shaft.

CDN $0.25

  • AWRENCH
